Fiber-to-the-Home Cable Production: How the Manufacturing Process Works
Quick fact: more than seventy percent of U.S. broadband rollouts now rely on fiber networks that require precise manufacturing to meet performance goals.
Shanghai Weiye OFC Equipment runs complete Fiber cable sheathing line manufacturing, from sourcing brand fibers like Fujikura® or Corning SMF-28e to complete test reports that deliver 100% QA.
Our FTTH drop designs fit overhead, underground, and direct-buried installation, with LSZH, PVC, and PE jacket options and core counts from 1–4 cores. We offer OS1/OS2 and multimode OM2–OM4 grades plus G.652D and ITU-T G.657 variants, Pantone sheath colors, and custom logo printing.
Automation and precision equipment keep line speed steady and repeatability high. Typical lead times run 4–5 days for orders under 100 km and 7–10 days for < 500 km, with an min. order of 1 km and free-replacement warranty for quality problems.
Continue to understand how materials, testing, and support work together to reduce lifecycle cost and match the right product to your network system.
- Shanghai Weiye OFC Equipment offers end-to-end manufacturing and lab testing for U.S. deployments.
- A range of jacket options and optical grades fit indoor/outdoor environments.
- Automated lines and machines provide stable quality and stable optical performance.
- Fast lead times, low minimums, and recognized brand fibers support reliable procurement planning.
- Complete reports and after-sales warranty back product reliability and compliance documentation needs.
Specialized FTTH Manufacturing by Shanghai Weiye OFC Equipment
When project timelines and performance matter, Shanghai Weiye OFC Equipment delivers tailored drop solutions with full test documentation.
As a focused supplier and manufacturer, Shanghai Weiye OFC Equipment combines purpose-built equipment with stringent material control. We offer customized service and products for residential/MDU deployments. Every order includes 100% quality assurance and full test reports.
Our lab runs high-temperature, salt spray, and vibration tests to validate durability. Jacket options cover LSZH, PVC, and PE. Designs include bow-type flat and self-supporting styles and support brand fibers such as Fujikura and Corning SMF-28e.
- Controlled production lines and in-process checks for shipments with audit trails.
- Technical support for specification reviews, trials, and volume ramp.
- Modern fixturing and calibration minimize variation so every cable matches operator specs.
FTTH Cable Production
At Shanghai Weiye OFC Equipment, manufacturing steps are matched to network specs, combining brand fiber choices with strict test routines.
Fiber Selection & Brand Options
We match fiber secondary coating line to minimum bend radius, loss, and deployment type. Options include OS1, OS2, OM2–OM4 and G.652D and G.657.A1/A2 per ITU-T. Brand fibers such as Fujikura® and Corning SMF-28e are offered to meet procurement standards.
Strength member integration
Strength members employ FRP (dielectric) or galvanized steel wire. FRP is preferred where non-conductivity is necessary. Steel wire provides tensile strength for longer aerial spans and bonding/grounding needs.
Jacket extrusion and process control
Jacket options include LSZH for flame/smoke safety, PVC for flexibility, and PE for UV/moisture resistance outdoors. Closed-loop control of temperature and capstan ratios keeps line speed stable and dimensional tolerances.
| Member | Dielectric FRP | Steel wire |
|---|---|---|
| Use case | Electrical isolation | High-tension aerial runs |
| Key benefit | Light, non-corrosive | High strength |
| Installer note | Simple terminations | Bonding/grounding required |
In-Process and Final Testing
Inline geometry/concentricity checks run during manufacturing. Final optical tests confirm loss and return loss. Each order ships with a full test report and lab results from high heat, salt-spray, and vibration trials to qualify field handling and drop terminations.
Typical lead times are 4–5 days for < 100 km and under 500 km in 7–10 days. Lot records and FAI approvals provide traceability and compliance for U.S. programs.
FTTH drop cable types and structures we manufacture
Shanghai Weiye OFC Equipment provides a focused portfolio of drop designs that fit indoor risers and long aerial runs. Each option pairs tested materials with geometry tuned for field termination and stable optical performance.
The flat bow-type drop minimizes footprint for risers and conduit. It keeps bend loss low for easy routing in hallways and MDUs.
Aerial Self-Supporting Options
Self-supporting FTTH drop designs use a support messenger to carry tensile loads. Choose dielectric FRP for electrical isolation or steel wire when bonding/grounding and higher tensile strength are required.
Strength member and core layouts
We offer dielectric and metallic strength member configurations to match safety and EMI rules. Central loose-tube and unitube flat types balance crush resistance and fiber secondary coating line for quick termination.
Indoor/outdoor jackets
Jacket choices include LSZH for flame-retardant, low-smoke indoor use and PE for outdoor UV and moisture resilience. Each family is validated for mechanical/optical performance before shipment.
| Design | Best use | Strength element | Sheath |
|---|---|---|---|
| Bow-type flat | Indoor risers and MDUs | Dielectric FRP | LSZH |
| Self-supporting (aerial) | Aerial spans | FRP/Steel | PE |
| Center loose tube | Higher-count builds | FRP | LSZH/PE |
| Unitube flat | Low-count, easy strip | FRP/Steel | LSZH/PE |
Production Assets for Speed and Quality
Automation and sensor-driven feedback at Shanghai Weiye OFC Equipment cut manual handling and boost throughput for drop patch preparation.
Our production line uses automated machines that cut/strip drop cords to increase output and cut labor variability.
The CLX-BPO2 automated stripper uses PLC + photoelectric control. One cycle is about 1.5 seconds, giving real-world speeds near 20 terminal operations per minute.
Automated Cut/Strip for Drop Cords
The equipment strips LSZH/PVC jackets and trims FRP/steel members to precise stub lengths. Cylinder-driven actuators deliver fast, repeatable motion and minimize downtime.
PLC/photoelectric control for precision and repeatability
PLC logic and photoelectric sensors give exact positioning and closed-loop control. Inline checks feed control charts so operators can correct trends before defects grow.
| Item | Capability | Benefit |
|---|---|---|
| CLX-BPO2 | 1.5s cycle, auto-strip | High throughput |
| Actuation | Cylinder-based | Fast/reliable motion |
| Material handling | LSZH & PVC; FRP & steel | Clean, accurate preps |
| Control | PLC + photoelectric + inline checks | Stable quality, reduced rework |
- Auto scrap ejection and ergonomic loading keep the line clean.
- Process control plans capture calibration intervals and critical parameters.
- Combined machines, fixtures, and trained staff help meet FTTH volume goals without sacrificing accuracy.
CLX-BPO2 auto-stripping machine capabilities in our line
The CLX-BPO2 brings industrial-grade stripping and trimming to our line, cutting cycle time while keeping prep consistent.
Shanghai Weiye OFC Equipment deploys the CLX-BPO2 to raise output and standardize prep quality. The unit cycles in ~1.5 seconds, producing around 20 preps per minute in production.
PLC/photoelectric control enable precise detection and repeatable actuation. That control keeps strip and stub lengths within tight tolerances.
Throughput & Cycle Time
Typical operation speed is 1.5s per cycle. This converts to steady throughput under normal production conditions.
Jacket Strip & Stub Lengths
The CLX-BPO2 handles LSZH/PVC with an adjustable strip length from 17.5–35.0 mm. Reserved stubs are adjustable from 7.0–11.0 mm to match common termination hardware.
FRP & Steel Member Handling
The machine cuts FRP/steel strength elements cleanly while protecting adjacent fibers. Custom tooling are available for nonstandard sizes to preserve precision.
- Automatic waste ejection and sensor-triggered start cut idle time.
- Compact size (L40 × W18 × H18 cm), 50W at 110–220V, and 11 kg mass ease integration into workcells.
- Cylinder-driven motion and closed-loop control boost reliability and lower maintenance interruptions.
| Spec | Value | Why it matters |
|---|---|---|
| Cycle | ~1.5 s (~20/min) | Supports high-volume runs |
| Strip lengths (A) | 17.5–35.0 mm | Compatible with common connectors |
| Reserved stub (B) | 7.0–11.0 mm | Meets strength and termination needs |
| Power & size | 50W @ 110–220V; 40×18×18 cm | Simple integration |
Using this machine, Shanghai Weiye OFC Equipment standardizes prep so field teams receive drop parts ready for quick installation. The CLX-BPO2 supports our lines in meeting volume targets without sacrificing quality.
Custom Specs for Your FTTH System
Shanghai Weiye OFC Equipment configures every order to fit your network requirements and simplify field rollout. We pair concise options with predictable manufacturing windows so your teams get install-ready reels.
Choose 1–4 core designs with single-mode or multimode fiber. Options include OS1, OS2, and OM2–OM4 along with G.652D/G.657 variants to match your optics and connector plans.
We Pantone-match sheath colors for quick field identification and consistent asset tagging.
Jackets, Legends & Branding
Select LSZH/PVC/PE jackets based on route and safety rules. Custom print legends and logos support inventory and warranty tracking.
Put-Ups, Packaging, and Structures
Standard put-ups are 1 km, 2 km, and 4 km with tailored reels and packaging to suit storage and handling. Choose bow-type flat or self-supporting designs and FRP or steel members to fit span and isolation requirements.
| Choice | Typical | Benefit |
|---|---|---|
| Length | 1 / 2 / 4 km | Simpler staging and reels |
| Sheath | LSZH / PE / PVC | Indoor/outdoor compatibility |
| Structure | Flat bow / Self-supporting | Routing and span flexibility |
As a supplier, Shanghai Weiye aligns runs to your schedule and delivers documentation that lists final specifications for easy on-site QA.
Quality, Test, and Docs
Shanghai Weiye OFC Equipment embeds quality checkpoints across the production line so every item has recorded acceptance data at ship.
Lab Testing: Heat, Salt Spray & Vibration
Our lab conducts elevated-temperature exposure, salt spray corrosion, and mechanical vibration to qualify materials/assemblies. These tests recreate field stresses for indoor and outdoor use.
Per-Reel 100% Reports
Every fiber optic cable ships with a 100% test report that logs attenuation, return loss, and geometry where applicable. Final QC gates prevent nonconforming shipments before they leave the factory.
Audit Trail and Compliance
Batch records tie test data to reels and serials so audits and warranty claims are simple to verify. Documentation uses standard customer templates to speed approvals and inbound inspection.
- In-line checks plus final inspection prevent field failures and cut warranty events.
- QA packages include specifications confirmation and formatted test data for rapid review.
- Continuous test trends inform preventive maintenance and raise long-term reliability.
| Trial | Purpose | Outcome |
|---|---|---|
| Heat exposure | Thermal stability | Validated heat endurance |
| Salt spray | Corrosion resistance | Outdoor suitability |
| Mechanical vibration | Resistance to vibration | Improved field reliability |
FTTH Drop Cable Pricing & Cost Drivers
Budget planning for a drop starts with fiber and jacket choices and is refined by volume and customization.
Typical prices range broadly—from about $30–$1,000 per unit—based on fiber grade, jacket material, length, and design structure.
Primary Cost Inputs
The primary cost drivers are fiber grade, sheath material, and the chosen structure for deployment.
Self-supporting designs and steel strength elements raise material and labor input. Custom colors, logos, and print legends add setup and impact pricing on small runs.
How Volume & Options Affect Cost
Longer reels and higher volume orders lower unit cost. Short runs often include setup charges and higher per-unit charges.
- Line changeovers and custom tooling extend lead time and add cost.
- Clear RFQs with schedule alignment let Shanghai Weiye OFC Equipment match quotes to delivery windows.
- Frameworks and indexed pricing stabilize budgets across phases.
| Driver | Effect on price | Recommendation |
|---|---|---|
| Fiber grade | Large | Right-size spec to budget |
| Jacket type | Medium | Compare LSZH vs. PE for total cost |
| Order length / volume | Large | Consolidate runs to cut unit cost |
Logistics for the U.S.
Shanghai Weiye OFC Equipment keeps lead times/logistics clear so planners can align crews and sites. Predictable windows reduce downtime and help control cost when a rollout is underway.
Production Windows & Capacity
Typical production windows run 4–5 days for orders under 100 km and 7–10 days for < 500 km. We plan capacity to track your milestones and to maintain on-time delivery.
The service team issues production updates and tracking so installation teams can plan arrivals. For compressed schedules, we hold contingency capacity to accelerate critical-path orders.
Minimum order quantity and why it matters
The MOQ is one kilometer. This reflects line setup such as wire and jacket die adjustments that use startup material and generate scrap.
We review your length and staging plans to choose reel sizes that cut waste and handling. Batch releases can balance inventory with more frequent small-site deliveries.
Where and How to Deploy
Site conditions dictate whether a self-supporting span, ducted pull, or direct-buried run is the right choice for a project.
Aerial vs Duct vs Direct-Buried
For aerial runs, Shanghai Weiye OFC Equipment recommends self-supporting designs with correct strength members to control sag and tension for long-term stability.
Duct installations perform best with low-friction sheaths and crush-resistant constructs so pulling does not damage fibers. PE jackets are typical for underground and buried paths where moisture resistance matters.
Direct-buried designs need correct burial depth per local codes and moisture barriers to protect the fiber core long-term.
Indoor riser/plenum distribution and ONT termination
Indoor riser and plenum routes favor LSZH jackets to meet flame and smoke rules. Flat drop cable forms strip cleanly and present controlled strength stubs for quick ONT termination.
We guide the choice of steel or FRP (dielectric) strength members based on bonding needs, lightning exposure, and hardware fit. Standardized line prep reduces install time and minimizes scrap.
| Scenario | Key design | Installer note |
|---|---|---|
| Overhead | Self-supporting, steel or FRP | Verify messenger hardware/tension |
| Underground duct | Low-friction jacket, crush resistance | Use pull tape and proper lubricant |
| Direct burial | PE with moisture barrier | Follow local depth and warning tape rules |
| Indoor | LSZH with tight-bend support | Maintain bend radius at wall penetrations |
Our approach delivers a consistent installation across indoor/outdoor transitions. That leads to fewer callbacks, speeds activations, and stable field performance for your system.
End-to-end support and after-sales service
Our team coordinates tests, line schedules, and installation guidance to avoid surprises in deployment.
Shanghai Weiye OFC Equipment provides engineering support from early requirements through approved drawings and pre-production builds. We provide doc templates and clear installation notes so field crews share a unified plan.
After-sales service covers rapid response, root-cause analysis, and corrective actions. All products ship with full test reports and traceability to support QA acceptance.
- 24/7 availability for status updates and technical guidance.
- Warranty includes free replacement for confirmed quality issues.
- Coordination of line schedules for urgent changes or acceleration requests.
- Config control so shipped items match agreed specs consistently.
| Support area | What we do | Outcome |
|---|---|---|
| Tech/Eng | Specs + pilots | Reduced field issues |
| Testing | Lab + 100% reports | Full traceability |
| Service | Rapid replacement & root-cause | Minimized downtime |
Wrap-Up
Choose Shanghai Weiye OFC Equipment for tailored drop builds, short lead times, and traceable quality records.
We deliver customized FTTH drop solutions that combine materials with validated manufacturing and lab tests. Every reel includes a 100% test report and documented trials to support field acceptance in the United States.
A robust production line, including CLX-BPO2 prep assets, cuts variability and speeds turnaround. Our equipment set standardize strip/stub lengths so installers get consistent results at turn-up.
From fiber selection through jacket, printing, and packaging, we balance performance and cost to extend service life. Dedicated customer support guides scheduling, logistics, and after-sales care so your deployment stays on plan.
Contact Shanghai Weiye OFC Equipment to align specs, timeline, and volume. We stand behind every shipment with laboratory validation and responsive service.
